Export a Path

  • Last edited on

Use this call to export a GPS path object for a specified target. Data is returned as either standard KML log file or binary GPS log file.

Request Data

Note: This operation is only supported in version 2.X.

Required Information
Name Description
action showposition
operation path
format kml or binary - binary is explained below
starttime Unix epoch timestamp
endtime Unix epoch timestamp
target The asset to query. If specified a reqtype (request type) must be specified as well.
reqtype Flag to identify the key being used to identify the asset. Acceptable values:
  • tag Key is a Zonar RFID tag number. In version 2.X a type must also be specified.
  • exsid Key is the external system id.
  • vin Key is the Vehicle Identification Number (VIN).
  • dbid Key is the internal database id number. This is the most reliable key to use.
  • fleet Key is the asset fleet number. In version 2.X a type must also be specified.
type When using reqtype of tag or fleet this must also be specified in version 2. See asset types for more details. Acceptable values are Standard or Trailer.
version API protocol version - version 2 only
logvers 2
Optional Information
tstype A flag to indicate what the starttime/endtime variables represent. Acceptable values are:
  • log Timestamp is the log point time. Log points after the starttime/before the endtime will be returned.
  • load Timestamp is the time the log point was added to the Zonar-Web system.  Log points that were uploaded after the starttime/before the endtime will be returned
If tstype is not specified, or is blank a value of 'log' will be assumed.
revgeocode A flag to indicate whether or not to reverse geocode the points returned. Acceptable values are:
  • true
  • false
If revgeocode is not specified, or is blank a value of 'false' will be assumed.

Note: This is currently only applied to CSV exports.

Request Data - Log Version 3+

Required Information
Name Description
action showposition
operation path
format xml, json, csv, kml or binary - binary is explained below
version API protocol version - version 2 only
logvers The supported versions are:
  • 3 - adds support for multiple assets in a single file and a checksum
  • 3.1 - adds an odometer reading and asset exsid to the csv export
  • 3.2 - adds fuel data, acceleromter and status information
  • 3.3 - adds zone attribute to event element in XML
  • 3.4 - adds exsid attribute to asset element in XML
  • 3.5 - adds units in header for fuel and acceleration (CSV only)
  • 3.6 - adds Total Fuel Used, Outside Temp, Average RPM, Average Load, Fuel Level fields to output for CSV and XML (other fields appear in output but will not be populated)
  • 3.7 - adds fields for Outside Pressure, Peak RPM, Average Torque, Boost Pressure, Fuel Filter Diff Pressure, Air Filter Diff Pressure, DPF Diff Pressure, Regen Status Flags (CSV and XML))
  • 3.8 - adds source as ECM or GPS for data and returns new log reason 13 (panic) (CSV, XML and JSON only)
starttime Unix epoch timestamp
endtime Unix epoch timestamp
Optional Information
If any optional information is omitted, all asset data for the given start/stop time period will be returned
target The asset to query. If specified a reqtype (request type) must be specified as well.
reqtype Flag to identify the key being used to identify the asset. Acceptable values:
  • tag Key is a Zonar RFID tag number. In version 2.X a type must also be specified.
  • exsid Key is the external system id.
  • vin Key is the Vehicle Identification Number (VIN).
  • dbid Key is the internal database id number. This is the most reliable key to use.
  • fleet Key is the asset fleet number. In version 2.X a type must also be specified.
type When using reqtype of tag or fleet this must also be specified in version 2. See asset types for more details.
tstype A flag to indicate what the starttime/endtime variables represent. Acceptable values are:
  • log Timestamp is the log point time. Log points after the starttime/before the endtime will be returned.
  • load Timestamp is the time the log point was added to the Zonar-Web system.  Log points that were uploaded after the starttime/before the endtime will be returned
If tstype is not specified, or is blank a value of 'log' will be assumed.
tsformat A parameter to indicate the format for timestamps in the XML output. Default value if none is passed is iso8601
  • iso8601 Timestamp is formatted according to iso8601 standards, yyyy-mm-dd hh:mm:ss-timezone
  • epoch Timestamp is formatted as an epoch timestamp.

Note: If tsformat is not specified then a value of iso8601 will be assumed.

Note: tsformat is only used with format=xml
revgeocode A flag to indicate whether or not to reverse geocode the points returned. Acceptable values are:
  • true
  • false
If revgeocode is not specified, or is blank a value of 'false' will be assumed.

Note: This is currently only applied to CSV exports. (Also in XML with logvers 3.8)
location Location to filter with. Text, the desired location name. If provided only positions data for assets assigned to that location will be returned.

You can find additional information on filtering your path results here.

Advanced Path Options

This section explains the more advanced options for filtering path information.

Name Description
bbox A bounding box used to limit results. The format is as follows: lon1, lat1, lon2, lat2 Where lat1, lon1 is the upper left corner of the box and lat2, lon2 is the lower right corner.
GPS Point Flags
standard A flag to indicate if you want to see standard gps points in your return data. Acceptable values are:
  • 0 - Do not show standard events.
  • 1 - Show standard events.
sc1 A flag to indicate if you want to see state change for input 1 gps points in your return data. Acceptable values are:
  • 0 - Do not show state change for input 1 events.
  • 1 - Show state change for input 1 events.
sc2 A flag to indicate if you want to see state change for input 2 gps points in your return data. Acceptable values are:
  • 0 - Do not show state change for input 2 events.
  • 1 - Show state change for input 2 events.
sc3 A flag to indicate if you want to see state change for input 3 gps points in your return data. Acceptable values are:
  • 0 - Do not show state change for input 3 events.
  • 1 - Show state change for input 3 events.
sc4 A flag to indicate if you want to see state change for input 4 gps points in your return data. Acceptable values are:
  • 0 - Do not show state change for input 4 events.
  • 1 - Show state change for input 4 events.
sc5 A flag to indicate if you want to see state change for input 5 gps points in your return data. Acceptable values are:
  • 0 - Do not show state change for input 5 events.
  • 1 - Show state change for input 5 events.
motionstart A flag to indicate if you want to see motion start gps points in your return data. Acceptable values are:
  • 0 - Do not show motion start events.
  • 1 - Show motion start events.

Note: If no value is passed for any of the GPS point flags, a value of 1 is assumed for all. If a value is passed for any of them, then the default value for any unspecified flags is treated as 0.
motionstop A flag to indicate if you want to see motion stop gps points in your return data. Acceptable values are:
  • 0 - Do not show motion stop events.
  • 1 - Show motion stop events.
panic A flag to indicate if you want to see panic gps points in your return data. Acceptable values are:
  • 0 - Do not show panic events.
  • 1 - Show panic events.
fence A flag to indicate if you want to see geofence gps points in your return data. Acceptable values are:
  • 0 - Do not show geofence events.
  • 1 - Show geofence events.
coldstart A flag to indicate if you want to see coldstart gps points in your return data. Acceptable values are:
  • 0 - Do not show coldstart events.
  • 1 - Show coldstart events.
poweron A flag to indicate if you want to see poweron gps points in your return data. Acceptable values are:
  • 0 - Do not show poweron events.
  • 1 - Show poweron events.
poweroff A flag to indicate if you want to see poweroff gps points in your return data. Acceptable values are:
  • 0 - Do not show poweroff events.
  • 1 - Show poweroff events.

Reason Codes

The reason attribute specifies one or more log reason codes as detailed below.

The flags listed above for GPS points correspond to the following reason codes in the returned data. For example if you specify poweron=1 and no other GPS flags you will only receive GPS points with a reason of 12 (Power on). Some points have multiple reasons, if any of the reasons is 12 eg. reason="6,12" you will receive them as well.

XML/JSON Reason Codes
Code Meaning
0 Reserved and invalid.
1 Input 1 state change
2 Input 2 state change
3 Input 3 state change
4 Input 4 state change
5 Input 5 state change
6 Cold Start
7 Power Off
8 Geofence
9 Motion Stop
10 Motion Start
11 Standard Event
12 Power On

Example XML Request

https://omi.zonarsystems.net/interface.php?customer=zzo2544&username=zonar&password=secret.pw.2019&action=showposition&operation=path&reqtype=dbid&target=191&version=2&starttime=1189321200&endtime=1189493940&logvers=3&format=xml

Example JSON Request

https://omi.zonarsystems.net/interface.php?customer=zzo2544&username=zonar&password=secret.pw.2019&action=showposition
&operation=path&reqtype=dbid&target=191&version=2&starttime=1189321200
&endtime=1189493940&logvers=3&format=json

Example XML Request logvers=3.2

https://omi.zonarsystems.net/interface.php?customer=zzo2544&username=zonar&password=secret.pw.2019&action=showposition
&operation=path&reqtype=dbid&target=8&type=Standard&version=2&starttime=1274710864
&endtime=1274743009&logvers=3.2&format=xml

 Data Returned

A standard KML log file, XML, CSV or binary GPS log file or error message.

KML Data Returned

Keyhole Markup Language (KML) is a standard XML file used for storing geographic data for display in Google Earth. A full specification and related information can be obtained from Google Earth KML 2.0.

Information about the KML file can be found in the "Document" element.

DTD

<!ELEMENT Document (#PCDATA | name | description | Style | Folder)*>
<!ELEMENT timePosition (#PCDATA)>
<!ELEMENT styleUrl (#PCDATA)>
<!ELEMENT width (#PCDATA)>
<!ELEMENT LineStyle (#PCDATA | color | width)*>
<!ELEMENT Style (#PCDATA | IconStyle | LineStyle)*>
<!ATTLIST Style id CDATA #IMPLIED>
<!ELEMENT href (#PCDATA)>
<!ELEMENT w (#PCDATA)>
<!ELEMENT h (#PCDATA)>
<!ELEMENT Icon (#PCDATA | href | y | w | h | x)*>
<!ELEMENT MultiGeometry (#PCDATA | LineString)*>
<!ELEMENT TimeInstant (#PCDATA | timePosition)*>
<!ELEMENT color (#PCDATA)>
<!ELEMENT kml (#PCDATA | Document)*>
<!ELEMENT Point (#PCDATA | coordinates)*>
<!ELEMENT description (#PCDATA)>
<!ELEMENT IconStyle (#PCDATA | Icon)*>
<!ELEMENT y (#PCDATA)>
<!ELEMENT Folder (#PCDATA | name | Placemark | Folder | description)*>
<!ELEMENT LineString (#PCDATA | coordinates)*>
<!ELEMENT name (#PCDATA)>
<!ELEMENT x (#PCDATA)>
<!ELEMENT coordinates (#PCDATA)>
<!ELEMENT Placemark (#PCDATA | name | styleUrl | MultiGeometry | description | TimeInstant | Point)*>

Binary Data Returned

A binary GPS log file consists of a single header(56 bytes) and subsequent position entries(28 bytes/ea).

Binary File Header Format

GPS Export Log File Header Format Log Versions 2 and 3
Total size 56 bytes. All offsets and sizes in bytes.
Offset Type Size Description
0 - 7 ASCII Text 8 ZGPSEXPT Identifies the file as a GPS export log file
8 - 11 Unsigned Integer 4 Version. Identifies the header and entry version. This layout must be maintained by all versions. Currently supported is 3.
12 - 19 ASCII Text 8 Account code, unused bytes are to be null.
20 - 23 Unsigned long 4 Extraction timestamp - this is when the request was made.
24 - 27 Unsigned long 4 Entry count - the number of log entries to follow
28 - 43 ASCII Text 16 Route identification - can be left NULL for now.
44 - 55 Empty 12 Padding so that the header is an even multiple of the entry size.
Total: 56



GPS Export Log File Header Format Version 3.2
Total size 56 bytes. All offsets and sizes in bytes.
Offset Type Size Description
0 - 7 ASCII Text 8 ZGPSEXPT Identifies the file as a GPS export log file
8 - 11 Unsigned Integer 4 Version. Identifies the header and entry version. This layout must be maintained by all versions. Currently supported is 3.
12 - 19 ASCII Text 8 Account code, unused bytes are to be null.
20 - 23 Unsigned long 4 Extraction timestamp - this is when the request was made.
24 - 27 Unsigned long 4 Entry count - the number of log entries to follow
28 - 43 ASCII Text 16 Route identification - can be left NULL for now.
44 - 55 Empty 12 Padding so that the header is an even multiple of the entry size.
Total: 56

Position Entry Layout

The file header will be followed by a series of position log entries. Each one will contain a timestamp, position, speed, heading, accumulated distance and information as to why the entry was recorded.

GPS Log File Entry Format Version 3
Total size 28 bytes. All offsets and sizes in bytes
Offset Type Size Description
0 - 3 Unsigned Long 4 Timestamp (Unix epoch)
4 - 7 Signed Integer 4 Latitude component (degrees / 10,000,000)
8 - 11 Signed Integer 4 Longitude component (degrees / 10,000,000)
12 - 13 Unsigned short 2 Speed (0.001 m/s)
14 Unsigned char 1 TBD
15 Unsigned char 1 TBD
16 - 17 Unsigned short 2 Heading (0.01 degrees)
18 - 21 Unsigned long 4 Accumulated distance (odometer). Meters
22 - 23 Unsigned short 2 Bit mask. See bitmap layout for details.
24 - 27 Unsigned long 4 Asset id. The database id for the asset this entry is associated with. Version 3 only.
Total: 28

Note: The accumulated distance/odometer in the binary log file differs from that given in a KML file. The binary log file accumulates the distance/odometer for the life of the GPS product. The KML odometer reads 0 at the start of the requested KML file.

Checksum Layout

Version 3 export files have a trailing checksum appended to them. This is a 4 byte unsigned long quantity containing a CRC32 checksum of all the preceding data, including the header.

XML/JSON Data Returned

Version 3 - DTD

<!ELEMENT pathevents (asset*)>
<!ATTLIST pathevents ver CDATA #REQUIRED>
<!ATTLIST pathevents assetcount CDATA #REQUIRED>

<!ELEMENT asset (event*)>
<!ATTLIST asset id CDATA #REQUIRED>
<!ATTLIST asset eventcount CDATA #REQUIRED>

<!ELEMENT event (#PCDATA)>
<!ATTLIST event lat CDATA #REQUIRED>
<!ATTLIST event long CDATA #REQUIRED>
<!ATTLIST event time CDATA #REQUIRED>
<!ATTLIST event speed CDATA #REQUIRED>
<!ATTLIST event heading CDATA #REQUIRED>
<!ATTLIST event reason CDATA #REQUIRED>
<!ATTLIST event distance_traveled CDATA #REQUIRED>

With JSON Add

<!ATTLIST event odometer CDATA #REQUIRED>
<!ATTLIST event loadts CDATA #REQUIRED>

Version 3.2 XML results - DTD

<!ELEMENT pathevents (asset*)>
<!ATTLIST pathevents ver CDATA #REQUIRED>
<!ATTLIST pathevents assetcount CDATA #REQUIRED>

<!ELEMENT asset (event*)>
<!ATTLIST asset id CDATA #REQUIRED>
<!ATTLIST asset eventcount CDATA #REQUIRED>

<!ELEMENT event (#PCDATA)>
<!ATTLIST event lat CDATA #REQUIRED>
<!ATTLIST event long CDATA #REQUIRED>
<!ATTLIST event time CDATA #REQUIRED>
<!ATTLIST event speed CDATA #REQUIRED>
<!ATTLIST event heading CDATA #REQUIRED>
<!ATTLIST event reason CDATA #REQUIRED>
<!ATTLIST event distance_traveled CDATA #REQUIRED>
<!ATTLIST event odometer CDATA #REQUIRED>
<!ATTLIST event loadts CDATA #REQUIRED>
<!ATTLIST event accel CDATA #REQUIRED>
<!ATTLIST event status CDATA #REQUIRED>
<!ATTLIST event fuel_counter CDATA #REQUIRED>
<!ATTLIST event fuel_units CDATA #REQUIRED>

Version 3.3 XML includes an additional attribute in the event element named zone

Version 3.4 XML includes an additional attribute in the asset element named exsid

Version 3.6 XML results - DTD

<!ELEMENT pathevents (asset*)>
<!ATTLIST pathevents ver CDATA #REQUIRED>
<!ATTLIST pathevents assetcount CDATA #REQUIRED>

<!ELEMENT asset (event*)>
<!ATTLIST asset id CDATA #REQUIRED>
<!ATTLIST asset eventcount CDATA #REQUIRED>

<!ELEMENT event (#PCDATA)>
<!ATTLIST event lat CDATA #REQUIRED>
<!ATTLIST event long CDATA #REQUIRED>
<!ATTLIST event time CDATA #REQUIRED>
<!ATTLIST event speed CDATA #REQUIRED>
<!ATTLIST event heading CDATA #REQUIRED>
<!ATTLIST event reasons CDATA #REQUIRED>
<!ATTLIST event distance_traveled CDATA #REQUIRED>
<!ATTLIST event odometer CDATA #REQUIRED>
<!ATTLIST event loadts CDATA #REQUIRED>
<!ATTLIST event accel CDATA #REQUIRED>
<!ATTLIST event status CDATA #REQUIRED>
<!ATTLIST event fuel_counter CDATA #REQUIRED>
<!ATTLIST event fuel_units CDATA #REQUIRED>
<!ATTLIST event address CDATA #REQUIRED>
<!ATTLIST event zone CDATA #REQUIRED>
<!ATTLIST event air_temp CDATA #REQUIRED>
<!ATTLIST event avg_rpm CDATA #REQUIRED>
<!ATTLIST event avg_load CDATA #REQUIRED>
<!ATTLIST event outside_pressure CDATA #REQUIRED>
<!ATTLIST event peak_rpm CDATA #REQUIRED>
<!ATTLIST event average_torque CDATA #REQUIRED>
<!ATTLIST event boost_pressure CDATA #REQUIRED>
<!ATTLIST event ffilter_dpressure CDATA #REQUIRED>
<!ATTLIST event afilter_dpressure CDATA #REQUIRED>
<!ATTLIST event dpf_dpressure CDATA #REQUIRED>
<!ATTLIST event regen_status CDATA #REQUIRED>

Version 3.7 XML is the same as version 3.6

Version 3.8 XML results - DTD

<!ELEMENT pathevents (asset*)>
<!ATTLIST pathevents ver CDATA #REQUIRED>
<!ATTLIST pathevents assetcount CDATA #REQUIRED>

<!ELEMENT asset (event*)>
<!ATTLIST asset id CDATA #REQUIRED>
<!ATTLIST asset eventcount CDATA #REQUIRED>

<!ELEMENT event (#PCDATA)>
<!ATTLIST event lat CDATA #REQUIRED>
<!ATTLIST event long CDATA #REQUIRED>
<!ATTLIST event time CDATA #REQUIRED>
<!ATTLIST event speed CDATA #REQUIRED>
<!ATTLIST event heading CDATA #REQUIRED>
<!ATTLIST event reasons CDATA #REQUIRED>
<!ATTLIST event distance_traveled CDATA #REQUIRED>
<!ATTLIST event odometer CDATA #REQUIRED>
<!ATTLIST event loadts CDATA #REQUIRED>
<!ATTLIST event accel CDATA #REQUIRED>
<!ATTLIST event status CDATA #REQUIRED>
<!ATTLIST event fuel_counter CDATA #REQUIRED>
<!ATTLIST event fuel_units CDATA #REQUIRED>
<!ATTLIST event address CDATA #REQUIRED>
<!ATTLIST event source CDATA #REQUIRED>

Reason Codes

The reason attribute specifies one or more log reason codes as detailed below.

XML/JSON Reason Codes
Code Meaning
0 Reserved and invalid.
1 Input 1 state change
2 Input 2 state change
3 Input 3 state change
4 Input 4 state change
5 Input 5 state change
6 Cold Start
7 Power Off
8 Geofence
9 Motion Stop
10 Motion Start
11 Standard Event
12 Power On
13 Panic - only with logvers 3.8

Regen Status Bitmask

For information on how to interpret bitmask values, see Status Mask.

Bit Description
0 Regening
1 Forced Regen
2 Regen Inhibited
3 Manual Inhibit
4 Clutch Inhibit
5 Brake (Service) Inhibit
6 Brake (Parking) Inhibit
7 PTO Inhibit
8 Throttle Pedal Inhibit
9 Neutral Switch Inhibit
10 Vehicle Speed (High) Inhibit
11 Vehicle Speed (Low) Inhibit
12 Exhaust Gas Temp Inhibit
13 Engine Temp (Low) Inhibit
14 Other System Inhibit

Example XML Success Reply

<pathevents ver="3" assetcount="2">
 <asset id="310" eventcount="4">
  <event lat="26.106157" long="-80.259347" time="2009-07-23 11:14:03-07" speed="0.0" heading="N" reasons="6,12,9" distance_traveled="0" odometer="209.2" loadts="2009-07-23 11:21:01.708821-07"/>
  <event lat="26.106193" long="-80.259270" time="2009-07-23 11:36:45-07" speed="0.0" heading="N" reasons="12,9" distance_traveled="0" odometer="209.2" loadts="2009-07-23 11:36:49.265859-07"/>
  <event lat="26.106189" long="-80.259282" time="2009-07-23 11:43:04-07" speed="0.0" heading="N" reasons="12,9" distance_traveled="0" odometer="209.2" loadts="2009-07-23 11:45:51.421893-07"/>
  <event lat="26.106154" long="-80.259297" time="2009-07-23 11:45:24-07" speed="9.5" heading="W" reasons="12,10" distance_traveled="0" odometer="209.2" loadts="2009-07-23 11:45:51.421893-07"/>
 </asset>
 <asset id="466" eventcount="2">
  <event lat="47.437398" long="-122.247567" time="2009-07-23 16:01:57-07" speed="0.0" heading="SSW" reasons="6,12,9" distance_traveled="8" odometer="1127.5" loadts="2009-07-30 11:18:00.275462-07"/>
  <event lat="47.437455" long="-122.247709" time="2009-07-23 16:13:15-07" speed="0.1" heading="S" reasons="12,10" distance_traveled="8" odometer="1127.5" loadts="2009-07-30 11:18:00.275462-07"/>
 </asset>
</pathevents>

Example JSON Success Reply

{
 "pathevents": {
 "ver": 3,
 "assetcount": 2,
 "assets": [
 {
  "id": 310,
  "eventcount": 4,
  "events": [
  {
   "lat": 26.1061566,
   "lng": -80.2593472,
   "time": "2009-07-23 11:14:03-07",
   "speed": "0.0",
   "heading": "N",
   "reasons": "6,12,9",
   "distance_traveled": 0,
   "odometer": 209.2,
   "loadts": "2009-07-23 11:21:01.708821-07"
  },
  {
   "lat": 26.1061934,
   "lng": -80.2592703,
   "time": "2009-07-23 11:36:45-07",
   "speed": "0.0",
   "heading": "N",
   "reasons": "12,9",
   "distance_traveled": 0,
   "odometer": 209.2,
   "loadts": "2009-07-23 11:36:49.265859-07"
  },
  {
   "lat": 26.1061886,
   "lng": -80.2592818,
   "time": "2009-07-23 11:43:04-07",
   "speed": "0.0",
   "heading": "N",
   "reasons": "12,9",
   "distance_traveled": 0,
   "odometer": 209.2,
   "loadts": "2009-07-23 11:45:51.421893-07"
  },
  {
   "lat": 26.106154,
   "lng": -80.2592971,
   "time": "2009-07-23 11:45:24-07",
   "speed": "9.5",
   "heading": "W",
   "reasons": "12,10",
   "distance_traveled": 0,
   "odometer": 209.2,
   "loadts": "2009-07-23 11:45:51.421893-07"
  }
  ]
 },
 {
  "id": 466,
  "eventcount": 2,
  "events": [
  {
   "lat": 47.4373983,
   "lng": -122.2475671,
   "time": "2009-07-23 16:01:57-07",
   "speed": "0.0",
   "heading": "SSW",
   "reasons": "6,12,9",
   "distance_traveled": 8,
   "odometer": 1127.5,
   "loadts": "2009-07-30 11:18:00.275462-07"
  },
  {
   "lat": 47.4374547,
   "lng": -122.2477094,
   "time": "2009-07-23 16:13:15-07",
   "speed": "0.1",
   "heading": "S",
   "reasons": "12,10",
   "distance_traveled": 8,
   "odometer": 1127.5,
   "loadts": "2009-07-30 11:18:00.275462-07"
  }
  ]
 }
 ]
 }
}

CSV Data Returned

CSV returns the following columns

Asset ID, Asset No., Date, Time(PDT), Speed(MPH), Heading, Log Reason,
Distance Traveled(Miles), Lat, Lon, Zone, Address

Logvers 3.1

Asset ID, Asset No., Date, Time(PDT), Speed(MPH), Heading, Log Reason,
Distance Traveled(Miles), Lat, Lon, Zone, Accumulated distance (Odometer in meters), EXSID

Logvers 3.2

Asset ID, Asset No., Date, Time(PDT), Speed(MPH), Heading, Log Reason,
Distance Traveled(Miles), Lat, Lon, Zone, Fuel Counter, Acceleration, Status Mask, Address

Logvers 3.3 CSV is the same as logversion 3.2



Logvers 3.5

Asset ID, Asset No., Date, Time(PDT), Speed(MPH), Heading, Log Reason,
Distance Traveled(Miles), Lat, Lon, Zone, Fuel Counter(Gallon),
Acceleration(Miles/Hour/Sec), Status Mask, Address

Logvers 3.6

Asset ID, Asset No., Date, Time(PDT), Speed(MPH), Heading, Log Reason,
Distance Traveled(Miles), Lat, Lon, Zone, Address, Odometer, EXSID,
Acceleration(Miles/Hour/Sec), Status Mask, Fuel Counter(Gallon), Air Temperature,
Average RPM, Average Load, Outside Pressure, Peak RPM, Average Torque, Boost Pressure,
FFilter Dpressure, AFilter Dpressure, DFP Dpressure, Regen Status

Logvers 3.7 CSV is the same as logversion 3.6



Logvers 3.8

Asset ID, Asset No., Date, Time(PDT), Speed(MPH), Heading, Log Reason,
Distance Traveled(Miles), Lat, Lon, Zone, Address, Source

Date is returned as YYYY-MM-DD.
Time is returned as HH:MM:SS in 24 hour format.
Log reason is returned as an English language string (eg 'Standard').

Example Request

https://omi.zonarsystems.net/interface.php?customer=zzo2544&username=zonar&password=secret.pw.2019&action=showposition
&operation=path&reqtype=dbid&target=191&version=2&starttime=1189321200
&endtime=1189493940&logvers=3.1&format=csv





GPS Track and Trace

See more
